Photo 3.3.2-1

4. The wiper blade assembly is held by two Phillip screws one on each side. see image below. Remove these

2 screws to slide out the assembly. See photo 3.3.2-2

Photo 3.3.2-2

Replace your assembly and reassemble your maintenance station back into the printer. Anytime the Wiper

Slider Assembly is replaced you will need to readjust the wiper blade height see section 2.5 for wiper blade

adjustment.
