Analog way Pulse 2 - 4.5 Hardware Specifications

15
4.4 Cable and adaptator informaon
A large choice of cables and adaptors are compable with the Pulse². Please refer to the hardware specicaons
chapter to nd the most suitable cables for your operaons.
For each type of signal, here are the levels and the impedance accepted by the Pulse².
4.4 
4.5 

Type Levels 
Composite 0,7 Vpp + 0,3 Vpp 75 Ω
S. Video Y = 0,7 Vpp + 0,3 Vpp
C = 0,7 Vpp
75 Ω
YUV Y = 0,7 Vpp + 0,3 Vpp
U = 0,7 Vpp
V = 0,7 Vpp
75 Ω
RGsB R = 0,7 Vpp
G = 0,7 Vpp + 0,3 Vpp
B = 0,7 Vpp
75 Ω
RGBS
R, G, B = 0,7 Vpp R, G, B = 75 Ω
S = 0,3 Vpp 75 Ω
or
S = TTL
Type Levels 
YUV Y = 0,7 Vpp + 0,3 Vpp
U = 0,7 Vpp
V = 0,7 Vpp
75 Ω
RGsB R = 0,7 Vpp
G = 0,7 Vpp + 0,3 Vpp
B = 0,7 Vpp
75 Ω
RGBS
R, G, B = 0,7 Vpp R, G, B = 75 Ω
S = 0,3 Vpp 75 Ω
or
S = TTL
Type 
HDBaseT RGB or YUV – 8 bits – 4.4.4 or 4.2.2 – 16/235
SD-SDI YUV - 10 bits – 4.2.2 - 270 Mb/s
No payload ID management
Only A-level type
DVI RGB ou YUV – 8 bits – 4.4.4 – 16/235 - TMDS
HDMI® RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 16/235 – TMDS
Type Levels 
YUV Y = 0,7 Vpp ±0,3 Vpp
U = 0,7 Vpp ±0,3 Vpp
V = 0,7 Vpp ±0,3 Vpp
75 Ω
RGsB R = 0,7 Vpp ±0,3 Vpp
G = 0,7 Vpp ±0,3 Vpp
B = 0,7 Vpp ±0,3 Vpp
75 Ω
Type 
HDBaseT RGB or YUV – 8 bits – 4.4.4 or 4.2.2 – 16/235
HD-SDI YUV - 10 bits – 4.2.2 – 1,485Gb/s and
1,485/1.001Gb/s
Only A-level type
Input and output payload ID management
for HDTV format only
3G-SDI YUV - 10 bits – 4.2.2 – 2,97Gb/s and
2,97/1.001Gb/s
Only A-level type
Input and output payload ID management
for HDTV format only
DVI RGB or YUV – 8 bits – 4.4.4 – 16/235 - TMDS
HDMI® RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 16/235 – TMDS
Type 
DVI RGB or YUV – 8 bits – 4.4.4 – 16/235 - TMDS
HDBaseT RGB or YUV – 8 bits – 4.4.4 or 4.2.2 – 16/235
HDMI® RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 16/235 – TMDS


Digital SDTV

Digital HDTV
Digital EDTV
These formats are compable with bi-level and tri-
level sync on 1 or 3 wires.
