8.1.1 Menu navigaon

8. OPERATING THROUGH THE FRONT PANEL

8.1 

To access the Pulse² menu, press the EXIT/MENU buon in the control

secon. To highlight items in the menu which will appear on the VFD

screen, turn the scroll knob le or right to the desired menu item. When

you have reached the desired menu item, press the ENTER buon in

the control secon to access that menu funcon. Pressing the ENTER

buon when a selecon has been made sets the value to that selecon

in the Pulse² memory. When all sengs have been made, press the

EXIT/MENU buon to exit sub-menus and return to the main menu.

Pressing the MENU buon in the menu secon of the Pulse², will display and give you access to the following

items on the menu VFD screen:

 select to choose which mode the Pulse² will work in (Mixer/Matrix mode),

 select to set the output types and resoluons of Output #1,

select to set the output types and resoluons of Output #2,

 select to congure the 8 individual input types and resoluons,

 select to store and use presets,

 select to change source image sengs of an input,

 select to access keying and tling controls and parameters when video layer is selected,

 setup your background color and your Quick Frame,

 select to adjust layer size, posion, border, transparency or transions,

 select to store (record), use and manage logos and frames into the Pulse²,

 select to access all audio input and output parameters,

 select to access device soware informaon, LAN sengs, reset factory sengs, and other user

oriented funcons.

* These items are only displayed if a valid input is assigned to the current layer (Pulse

- Ref. PLS350-3G and

Ref. PLS350-H only)

The Pulse² oers 2 modes to work from: the Mixer mode and the Matrix mode which turns your Pulse² into

a true 8 x 2 scaled matrix with numerous eects and PIPs and logos.

To choose which mode the Pulse² will operate in, press the EXIT/MENU buon and select mode in the menu

by rotang the scroll knob. Then press the ENTER buon to enter the MODE sub-menu. Select the desired

mode by rotang the scroll knob, and press the ENTER buon to conrm your choice. Press the EXIT/MENU

buon to return to the main menu.







Simply selecng a menu item will not set it to that value. Be sure to press the ENTER buon when

parametering the menu items or to push the scroll knob.
