4.5.2 Supported video formats
The Pulse² can support all the following video formats:
 The maximum pixel clock frequency is 165 MHz. Supported formats include 1920x1200 @ 60hz
RB, 1600x1200 @60hz RB, 2048x1152 @60hz RB.
The Pulse² inputs support GTF (version 1.1), CVT (version 1.1) and DMT (version 1.0 rev 12) standards. All
others non-standard formats are supported via the custom format capability of the framework.



Type Levels 
RGsB R = 0,7 Vpp
G = 0,7 Vpp + 0,3 Vpp
B = 0,7 Vpp
75 Ω
RGBS
R, G, B = 0,7 Vpp R, G, B = 75 Ω
S = 0,3 Vpp 75Ω or S = TTL
RGBHV
R, G, B = 0,7 Vpp R, G, B = 75 Ω
H = TTL and V = TTL
Type 
HDBaseT RGB or YUV – 8 bits – 4.4.4 or 4.2.2 – 0/255
DVI RGB – 8 bits – 4.4.4 – 0/255 - TMDS
HDMI® RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 0/255 – TMDS
 
Standard   
NTSC 525/480i 59.94Hz/60Hz 15,735 KHz
PAL 625/576i 50Hz 15.625 KHz
SECAM 625/576i 50Hz 15.625 KHz

Standard   
480p 525/480p 59.94Hz/60Hz 31.47 KHz
576p 625/576p 50Hz 31.25 KHz

Standard  
720p 1280 x 720 23.97Hz/24Hz/25Hz/29,97Hz/30Hz/50Hz/59.94Hz/60Hz
1035i 1920 x 1035 59.94Hz/60Hz
1080i 1920 x 1080 50Hz/59.94Hz/60Hz
1080sF 1920 x 1080 50Hz/59.94Hz/60Hz
1080p 1920 x 1080 23.97Hz/24Hz/25Hz/29,97Hz/30Hz/50Hz/59.94Hz/60Hz

  
DCDM 2048 x 1080 24Hz

