77
10.1 HDCP
10. APPLICATIONS NOTE AND TIPS
HDCP is a content protecon mechanism which uses encrypon to prevent high value content from being
delivered to non-authorized devices. For example, Blu-ray players use HDCP on their HDMI outputs to ensure
that the HDMI output cannot be routed to a digital recording device.
The Pulse² is fully HDCP compliant, meaning that you will be able to use the Pulse² to accept HDCP protected
sources and route them to any HDCP protected outputs. As Analog Way is a licensed HDCP adaptor, this also
means that the Pulse² is prevented from displaying any HDCP protected images on any non-HDCP compliant
outputs (as is the case for all licensed HDCP compliant devices).
HDCP can only be used on certain connecon formats, including DVI, HDMI, and DisplayPort. Keep in mind
that simply because a connecon is using a DVI, HDMI, or DisplayPort connecon, it does not guarantee
that the devices connected are maintaining an acve HDCP connecon. For example, you may nd video
recording or capture devices equipped with an HDMI input, however HDCP licensing forbids these devices
from capturing HDCP protected content.
HDCP is not supported on connecon formats such as composite, component, S.Video, SD-SDI, HD-SDI,
3G-SDI, or VGA. This means that any source which becomes protected by HDCP cannot be converted to
these formats. For example, while you may nd a Blu-ray player which can directly output a composite video
signal, HDCP licensing forbids converng the HDCP protected HDMI signal back to composite or any other
non-protected format.
To help troubleshoot HDCP in your installaon, each input and output page is equipped with HDCP status
informaon to indicate in realme when HDCP encrypon is being used.
Certain devices such as Macintosh computers can be misleading to use in conjuncon with an HDCP
compliant presentaon switcher such as the Pulse². This is because devices like the Mac computers can be
used to output both HDCP protected content (such as a movie downloaded from iTunes) as well as non-
HDCP protected content (such as a Keynote presentaon or the desktop). When a computer rst connects
to an HDCP compliant device such as the Pulse², it learns the capabilies of the device through the EDID
connecon. Upon seeing the HDCP compability of the aached Pulse², devices like the Mac computers will
immediately aempt to use HDCP encrypon at all mes, despite the content currently displayed on the
computer screen. Since this source would now be considered an HDCP protected source, the Pulse² would
be required to prevent it from being displayed on VGA or SDI outputs and only allow it to be displayed on
outputs protected by HDCP. To work around this problem, the Pulse² allows the HDCP features of a parcular
input to be disabled, which in turn informs the Mac computer to avoid using HDCP, and allows content such
as Keynote and the desktop to be displayed, as this input will no longer use HDCP protecon. Please note
that disabling the HDCP features of the input do not circumvent HDCP protecons, and thus do not allow you
to view any content which requires this protecon.
For more informaon about HDCP, please refer to our whitepapers on HDCP, or visit the HDCP foundaon
website.
