8.4 Menu tree
8.4 Menu tree
MIXER MODE MATRIX MODE
OUTPUT #1
OUTPUT #2
OUTPUT #1
OUTPUT #2
FORMAT:1920X1080
RATE: 50.00HZ
LOCK: INTERNAL
FORMAT:1920X1080
RATE: 50.00HZ
LOCK: INTERNAL
FORMAT:1920X1080
RATE: 50.00HZ
LOCK: INTERNAL
FORMAT:1920X1080
RATE: 50.00HZ
LOCK: INTERNAL
| PROG.|PRVW.
---------+---------+----------
Logo2 |Logo#1|Logo#8
Logo1 |Logo#1|Logo#7
LayerB|DVI 1 |DVI 2
LayerA|Input1|Input8
Frame |Frame1|Frame8
|SCR#1 |SCR#2
---------+----------+---------
LayerA|Input1 |SDI 2

In Matrix mode, you will nd a new menu into Preset menu called “Preset management”. This will help you
to dene what kind of preset you want to save:
 preset saved for both outputs,
 preset saved only for the current output,
 preset saved only for output #1,
 preset saved only for output #2.

Please see the Mirror mode features. (page 44)
