A standard RS232 interface is available through a DB9 female connector:
- It permits controlling the device
- It permits updang the device
Data Rate: 1200 to 115200 Bauds, 8 data bits, 1 stop bit, no parity bit, no ow control by default.
DTR & RTS needed for rmware upgrade.
4.8 
4.8.1 Serial interface

4.8.2.2 IP address
4.8.2 LAN interface
4.8.3 HDBaseT LAN interface
4.8.4 IR and SERIAL HDBaseT interface
 Availability
TCP Yes
UDP Yes
 Availability
Stac user dened address Yes
A standard LAN interface is available through a RJ-45 connector
- It permits controlling the device
- It permits transferring conguraon
- It permits connecvity with the RCS² applicaon
- It permits updang the device
Default IP address: 192.168.2.140

For the references PLS350-3G and PLS350-H,
the Pulse² has one video output. This video
output contains:
- 3G/HD/SD-SDI (BNC).
Output Type  Signal
3G/HD/SD-SDI Output
SDTV
HDTV
Cinema
Digital SDTV
Digital HDTV
DCDM 2K
The HDBaseT input and ouput connectors of the Pulse
2
(reference PLS350-
H) can manage an Ethernet passthrough signal.
A specic LAN over HDBaseT connector is available on the Pulse2 to be
connected to the dedicated network.
The HDBaseT LAN could not be used to manage the device.
Associated to each HDBaseT output connectors, the 5-pin MCO connector can passthrough the one-way
InfraRed and the Bidireconal Serial RS232 signals to the HDBaseT output interface.
The pins #1 to #3 are used for the HDBaseT Serial RS232 connecon, respecvely for the transmission (TX),
the recepon (RX) and the Ground RS232 signals.
The pins #4 and #5 of the MCO connector are dedicated for the HDBaseT IR signal, respecvely for the
recepon (RX) and for the Ground signals.
Please note that some IR sensors could have a low power signal which could not be compable with the
expected IR input characteriscs of the Midra
TM
. In case of issue, make sure to use professional IR controller.
