27
1.  100-240 VAC 2.5A 50/60HZ / FUSE F4A 250 VAC; internal, autoswitchable; 110W
2. 3G/HD/SD-SDI: SDI #1 to #2
3. S/PDIF: audio inputs #1 to #2
4.  for audio inputs (balanced) #1 to #4
5.  for audio outputs (balanced) #1 to #2
6. S/PDIF: audio outputs #1 to #2
7. 1x BNC-F: 3G/HD/SD-SDI (with audio embedded)
8.  inputs #1 to #4
9.  DVI-D inputs #1 to #4. Capability to receive digital audio signal from HDMI connector via
an adaptor (HDMI-compable)
10. 
11.  HDMI inputs #3 & #4 / HDMI 1 & HDMI 2
 communicaon port with DB9 female connector
 HD15 outputs #1 to #2
  DVI-I outputs #1 to #2. Capability to transmit digital audio signal towards a HDMI
connector via an adaptor (HDMI-compable)
5.1.3 Rear panel Pulse
2
- Ref. PLS350-3G
1 2 3 4 5 6 7
9
10
12
8
11
1413
5.1.3 Rear panel Pulse
2
- Ref. PLS350-3G
