7.2.7 Input management
- CONTROL: Black: select Black to transform your input in a uniform color (black).
 use this buon to freeze the specic input,
- EDID: choose the EDID for the selected plug.
Under the HDCP secon, you can:
- Enable/disable the HDCP communicaon feature
- Read the HDCP status, If the HDCP status says Acve, this output connecon is
currently ulizing HDCP to protect the signal. if the HDCP status indicates Idle, this
output connecon is currrently not ulizing HDCP.
Next is the IMAGE tab, where you can nd all sengs about the display of your input:
Under the COLORIMETRY secon, you have:
- BRIGHTNESS: dene the selected input luminosity level,
- CONTRAST: dene the selected input contrast level,
- COLOR: dene the selected input color level (0:black and white, full: full color),
Under the SHARPNESS secon, you have:
- LEVEL: dene the selected input sharpness level,
Under the USER GAIN secon, you nd:
- THE RED/GREEN/BLUE: increase/decrease the Red/Green/Blue level of your input.
Next you have the ASPECT tab. All sengs about the blanking and aspect rao are available there:
For the analog inputs, the blanking secon is available.
Under the BLANKING ADJUSTMENTS:
- you can manually adjust the input blanking with the V&H size or posion.
