7-3 Ethernet Configuration on the Site Master Ethernet Connectivity (Option 411)
7-4 PN: 10580-00252 Rev. J Site Master User Guide
To display the IP address with the instrument on, press the Shift key, then the System (8)
key, then the
System Options soft key and the Ethernet Config soft key. The IP address will be
displayed as shown in Figure 7-1. The image on the display panel of your Site Master may
differ from the image shown here.
Figure 7-1. IP Address Assigned Using DHCP
