SECTION 2 – COMPONENTS
DETECTION CIRCUIT CABLE
Part No. See table
Detection Circuit Cable Length
Part Number ft (m)
FIGURE 2-9
DETECTION CIRCUIT CABLE
DETECTION CIRCUIT BULKHEAD CONNECTOR
Part No. 439404
FIGURE 2-10
DETECTION CIRCUIT BULKHEAD CONNECTOR
DETECTION CIRCUIT TEE
Part No. 439394
Figure 2-11.
FIGURE 2-11
DETECTION CIRCUIT TEE
DETECTION CIRCUIT EOL (End-of-Line) DEVICE
Part No. 439396
Provides circuit supervision and termination point for main
detection circuit. See Figure 2-12.
FIGURE 2-12
DETECTION CIRCUIT EOL
DETECTION CIRCUIT BRANCH TERMINATOR
Part No. 439398
Figure 2-13.
FIGURE 2-13
DETECTION BRANCH TERMINATOR
CHECKFIRE 110
Detection and Actuation System
