Anviz EP300 User Manual

6
Menu
fUser
Setup
USB Flash
Press [OK] key to enter the sub-menu,
User ▼
fEnroll
Delete
Verify Mode
2.3.1 User enroll
One user can register 2 fingerprints and 1 password.
Enter fingerprint:
Enter [User] menu-[Enroll] option, press [OK] key to enter user registration
interface. Input user ID, i.e. 8101,
Enroll
ID 008101
Esc-C Set-OK
Press [OK] key to continue,
Enroll
FP 1/2
Password
Esc-C Set-OK
1 means enroll the 1st FP
2 means enroll the 2nd FP
Press [→] key to select 1 or 2, 1 is to register the 1
st
FP, 2 is to register the 2
nd
FP.
Press [OK] key to continue,
FP Enroll
Press Finger #1

Anviz EP300 Specifications

General

Type	Basic access control reader
Resolution	500
Certification	FCC, CE
Product color	Black
Number of users	1000 user(s)
Housing material	Carbon
Scan speed (min)	0.5 mm/sec
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Password
Display type	LCD
Display size (HxV)	128 x 64 mm
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	35 mm
Width	185 mm
Height	130 mm
