APRILIA TUONO V4 R a-PRC ABS User Manual

Specification Desc./Quantity
Fuel tank reserve 4 l (0.88 UK gal; 1.06 US gal)
Engine oil oil and filter change 4 l (0.88 UK gal)
Coolant 2.6 l (0.57 UK gal)
Seats 2
Maximum weight capacity 195 kg (429 lb)
Drive chain
DRIVE CHAIN
Specification Desc./Quantity
Type 525
With sealed master link
Model Regina 110 links
Electrical system
ELECTRICAL SYSTEM
Specification Desc./Quantity
Spark plugs NGK CR9EKB
Electrode gap 0.7 - 0.8 mm (0.027 - 0.031 in)
Battery YUASA YT12A-BS, 12 V 9.5 Ah
Coils Stick coil
Recharging system Flywheel with rare earth magnets
Alternator 450 W
Main fuses 30 A
Secondary fuses 5A - 7.5A - 15A
ABS fuses 15A - 30A
BULBS
Specification Desc./Quantity
High beam/low beam light 12 V - 55 W H7
Front daylight running lights LED
Turn indicators 12V - 10W (White light)
Rear daylight running light /stop light LED
License plate light 12 V - 5 W
WARNING LIGHTS
Specification Desc./Quantity
High beam light LED
Right turn indicator LED
Left turn indicator LED
General warning LED
Gear in neutral LED
Side stand down LED
Fuel reserve LED
ABS LED (WHERE ACTIVE)
Frame and suspensions
CHASSIS
Specification Desc./Quantity
Type Aluminium, dual beam chassis with pressed and cast sheet el-
ements.
Steering rake 27°
TUONO V4 R a-PRC ABS Characteristics
CHAR - 13
