Remove the left bearing (18) with the
specific extractor.
•
Collect the inside spacer (19).
•
Remove the right bearing (20) with the
specific extractor.
•
Retrieve the right hand spacer (21).
•
Clean the inside of the hub thoroughly.
CAUTION
WASH ALL COMPONENTS WITH CLEAN DETERGENT
SOLUTION.
Specific tooling
AP8140180 Bearing extractor
TUONO V4 R a-PRC ABS Suspensions
SUSP - 421
