Disconnect the fuel pipe.
•
Disconnect the fuel pump connector.
•
Remove the tank.
Front mudguard
•
Working on both sides of the vehicle,
undo and remove the two screws.
•
Remove the front mudguard.
Instrument cluster support
REMOVAL
•
Remove the instrument panel.
•
Working on both sides, unscrew and
remove the two screws fastening the
arch brace to the headstock.
•
Retrieve the cable grommet.
Bodywork TUONO V4 R a-PRC ABS
BODYW - 512
