Use the special tool to remove the
semi-bushings.
CAUTION
CHECK THAT THE ORs ON THE TOOL ARE NOT DAM-
AGED.
Specific tooling
020861Y Countershaft bushing punch
See also
Balancing
countershaft removal
Crankcase opening
Crankshaft check
Characteristic
Maximum crankshaft axial clearance after
closing the crankcase
0.5 mm (0.0197 in)
Maximum radial clearance between the main
bearings and the crankshaft pins
0.05 mm (0.00197 in)
Balancing countershaft check
Characteristic
Maximum countershaft axial clearance after closing the crankcase
0.1 mm (0.0039 in)
Engine TUONO V4 R a-PRC ABS
ENG - 350
