Disconnect the two exhaust butterfly
valve control cables
•
Unscrew and remove the screw from
the cable grommet for the two exhaust
butterfly valve control cables.
CAUTION
ON REASSEMBLY, POSITION AND TIGHTEN THE SCREW
BUT NOT THE CABLE GROMMET.
•
Release the springs between the rear
exhaust manifolds and the catalytic
converter
•
Remove the catalytic converter.
Removing the exhaust manifold
2 IN 1 FRONT EXHAUST MANIFOLD
•
Remove the front underfairings.
•
Remove the hand grip position sensor control unit.
Chassis TUONO V4 R a-PRC ABS
CHAS - 444
