Removing
•
Drain the engine oil.
•
Remove both fairings and the radiator
cowl.
•
Release the clamp and disconnect the
right hand radiator pipe.
•
Release the clamp and disconnect the
left hand radiator pipe.
See also
Replacement
•
Remove the split pin.
•
From the opposite site, remove the
coolant radiator-oil radiator connector
pin.
•
Unscrew and remove the lower radia-
tor retainer.
•
Remove the radiator, draining com-
pletely of oil.
Chassis TUONO V4 R a-PRC ABS
CHAS - 448
