APRILIA TUONO V4 R a-PRC ABS User Manual

•
Flywheel lock cod. 020914Y
FIND BELOW THE REMOVING AND REFIT-
TING PROCEDURE OF THE MITSUBISHI FLY-
WHEEL, THE SAME PROCEDURE (EXCEPT
FOR TOOLS) IS VALID ALSO FOR KOKUSAN
FLYWHEEL.
See also
Removing the flywheel cover
•
Remove the flywheel cover.
•
Block flywheel rotation using the spe-
cific tool.
•
Unscrew and remove the screw.
Specific tooling
020848Y Flywheel retainer
•
Remove the tool for blocking flywheel
rotation.
•
Insert a SHC M10x20 screw into the
crankshaft hole, which will act as a
mounting base for flywheel extraction.
•
Remove the flywheel using the specific
extractor.
•
Collect the SHC M10x20 screw.
Specific tooling
020847Y Flywheel extractor
See also
Removing the flywheel cover
TUONO V4 R a-PRC ABS Engine
ENG - 275
