Undo the counter-lock ring, remove the
safety washer then unscrew the lower
lock ring in order to adjust the steering
free play correctly.
•
Adjust the pre-loading of the steering
bearings by tightening the lower ring
nut to the prescribed torque.
•
Turn the steering 3-4 times completely
from right to left and then check correct
tightening torque of such ring nut.
•
Place the safety washer, bending two opposite tongues inside the ring nut notches.
•
Mount the upper ring nut and tighten it
manually, another 35 degrees so that
the grooves match the safety washer
tongues.
•
Fit the upper fork plate by performing
demounting operations in reverse or-
der.
TUONO V4 R a-PRC ABS Suspensions
SUSP - 413
