Rear
REAR WHEEL
pos. Description Type Quantity Torque Notes
1 Rear wheel axle nut M25x1.5 1 120 Nm (88.51 lb ft) -
2 Screws fastening sprocket on
sprocket mount
M10 5 50 Nm (36.88 lb ft) -
Removing the rear wheel
•
Place the vehicle on the specific rear
support stand.
•
Loosen and remove the nut on the
wheel pin.
•
Recover the shoulder ring and the left
chain tensioner pad.
Suspensions TUONO V4 R a-PRC ABS
SUSP - 414
