Take out the crankshaft.
Bearing removal
AS A RESULT OF UPDATES, IT IS POSSIBLE TO IDENTIFY SOME ENGINES WITH COUNTER-
SHAFT ON THE HALF BUSHINGS AND OTHERS WITH COUNTERSHAFT ON BEARINGS.
(OPTION 01)
BALANCING COUNTERSHAFT BEARING RE-
MOVAL
•
Remove the lower crankcase.
•
Remove the countershaft.
FLYWHEEL-SIDE
•
Unscrew and remove the bearing re-
tainer screw.
•
Remove the lock.
•
Heat up the crankcase to 150°C (302°
F).
•
Position the general tool to pull out
bearings.
•
Remove the bearing.
See also
Crankcase opening
Engine TUONO V4 R a-PRC ABS
ENG - 348
