APRILIA TUONO V4 R a-PRC ABS User Manual

FRONT FORK - SACHS
pos. Description Type Quantity Torque Notes
1 TEFL screw (fasten onto Fork Hubs) M6x40 4 10 Nm (7.37 lb ft) -
2 Screw (Piston fixing to the stem
base)
- 2 30 Nm (22.13 lb ft) -
3 Upper cap - 2 20 Nm (14.75 lb ft) -
4 Upper cap locking nut - 2 20 Nm (14.75 lb ft) -
- Speed sensor bracket screw M5x12 1 0.6 Nm (0.44 lb ft) -
Characteristics TUONO V4 R a-PRC ABS
CHAR - 16
