Position the special tool from the alter-
nator side in order to not ruin the edges
of the oil seal.
•
Insert the gearbox unit in the crank-
case.
Specific tooling
0277308 Guide bushing for gearbox secondary
shaft
•
Remove the special tool from the alter-
nator side.
•
Tighten the six screws that fasten the
gearbox unit to the crankcase.
Specific tooling
0277308 Guide bushing for gearbox secondary
shaft
Engine TUONO V4 R a-PRC ABS
ENG - 268
