Block clutch bell rotation using the spe-
cific tools.
•
Unscrew and remove the clutch bell
fixing nut.
Specific tooling
020849Y Clutch lock
•
Remove the slipper unit.
•
Remove the clutch hub.
•
Remove the clutch hub cam tower.
Engine TUONO V4 R a-PRC ABS
ENG - 280
