Remove the intake and exhaust camshafts from the rear head.
•
Unscrew and remove the mobile chain
slider screw.
•
Remove the mobile chain slider.
•
Unscrew and remove the fixed chain
slider screw.
•
Remove the fixed chain slider.
•
Remove the camshaft control gear
connected with a clamp to the timing
chain.
•
Unscrew and remove the two head fas-
tener screws (a - b) from the clutch
side.
Engine TUONO V4 R a-PRC ABS
ENG - 322
