Remove the key on countershaft
•
Remove the spacer.
•
Remove the countershaft on the oppo-
site side.
BALANCING COUNTERSHAFT FITTED ON
BUSHINGS
•
Block crankshaft rotation using the
specific tool.
Specific tooling
020850Y Primary gear lock
TUONO V4 R a-PRC ABS Engine
ENG - 339
