Using the suitable tools, fit the bearing
in the crankcase until tool stops
•
Fit the retainer in the bearing groove.
•
Tighten the bearing retainer screw.
CLUTCH-SIDE
•
Heat up the crankcase to 150°C (302°F).
•
Prepare the following tools:
Specific tooling
020363Y 20 mm diam. punch for crankshaft oil seal
020359Y 42 x 47 mm punch
020376Y Sleeve for adaptors
•
Position the new bearings with their
groove on the outside diameter facing
outward with respect to the crankcase.
In this way it will be possible to install
the bearing retainer in the groove.
Engine TUONO V4 R a-PRC ABS
ENG - 360
