The procedure then continues with screws 1 and
4
If it is necessary to intervene on Master screws
(1-4), proceed as follows:
•
Remove the filter casing cover.
•
Remove the remaining cones by undo-
ing the eight screws (1).
•
Remove the two covers (2).
CAUTION
WHEN REFITTING THE COVERS PAY ATTENTION TO NOT
DAMAGE THEM.
To ensure correct engine operation, one of the two screws of each throttle body must always be closed.
Motorcycles are factory set with screws 1 and 2 turned by half a turn and screws 3 and 4 closed.
See also
Air box
Power supply TUONO V4 R a-PRC ABS
P SUPP - 390
