APRILIA TUONO V4 R a-PRC ABS User Manual

•
PIN 12 (White/Brown) - Front speed sensor positive
•
PIN 13 (Yellow/Brown) - Rear speed sensor positive
•
PIN 14 (Yellow) - Rear speed sensor input
•
PIN 17 (Blue/Red) - ABS warning light
•
PIN 18 (Orange/Green) - Battery for ABS pump engine positive
Operating diagram
Braking system TUONO V4 R a-PRC ABS
BRAK SYS - 452
