TAIL
pos. Description Type Quantity Torque Notes
1 Screws used to fasten the small side
fairings to the tank
M5 2+2 2 Nm (1.48 lb ft) -
2 Screws used to fasten the small side
fairings to the tail fairing
M5 1+1 1 Nm (0.74 lb ft) -
3 Screws fastening the grab handle
shell
SWP 3.9 11 1.5 Nm (1.10 lb ft) -
4 Rear screws used to fasten the grab
rail to the headlight support bracket
M6 2 8 Nm (5.90 lb ft) -
5 Front screws fastening grab handle
to saddle support bracket.
M6 2 8 Nm (5.90 lb ft) -
TUONO V4 R a-PRC ABS Bodywork
BODYW - 499
