Fasten the main cable harness to the
semi-arch brace with a clamp.
•
Gather the cables on the right semi-
arch brace and fasten them provision-
ally with a clamp.
•
Fit the left semi-arch brace, applying
the five coupling screws. Do not strain
the connection between the two semi-
arch braces, as this would prevent the
removal of the clamp.
•
Cut and remove the provisional clamp.
•
Fit the cable grommet from the left
hand side of the arch brace, tighten the
two screws on the headstock.
•
Tighten the five coupling screws.
•
Fit the turn indicator connectors in the
relative housings, noting the colours of
the wires identifying the correct side.
Bodywork TUONO V4 R a-PRC ABS
BODYW - 514
