4. REPLACE THE CONTROL UNIT - END
•
5. CHECK CONTINUITY OF PINK CABLE BETWEEN SWITCH CONNECTOR AND PIN
58 OF THE CONTROL UNIT, CHECKING ALSO THE ENGINE - VEHICLE CABLE HAR-
NESS CONNECTOR
YES, go to 4; NO, restore the cable harness - END
•
6. CHECK CONTINUITY OF PINK/BLACK CABLE BETWEEN SWITCH CONNECTOR
AND PIN 4 OF THE CONTROL UNIT, CHECKING ALSO THE ENGINE - VEHICLE CABLE
HARNESS CONNECTOR
YES, go to 4; NO, restore the cable harness - END
•
7. REPLACE THE STARTER BUTTON COMPONENT - END
Troubleshooting TUONO V4 R a-PRC ABS
TROUBL - 92
