Chapter 3: Configuration and commissioning
34 1X-X3 Installation Manual
Advanced configuration
The default password for advanced configuration is 4444. After entering the
password, the first displayed menu is the Advanced default configuration
(indicating advanced installer user level). For more information see “User level
passwords and indications” on page 24.
The advanced configuration menu
Configuration options for this menu are shown in the table below. More
information for each option is included in the related topic.
Table 12: The advanced configuration menu
Display Menu Values
Advanced default configuration See Table 11 on page 30
Panel mode Basic standard
Basic evacuation
Custom
Actuator delay 00 to 60 seconds
Reset disabled delay 00 to 30 minutes
Safety door monitoring ON/OF
Safety door fault delay 10 to 90 seconds
Pressure switch type Normally closed
Normally open
Hold mode Mode A
Mode B
Activation tone Pulsed
Continuous
Released tone Pulsed
Continuous
Extinguishing zones Z1 extinguishing, Z2 and Z3 fire
Z1 and Z2 extinguishing. Z3 fire
Z1, Z2, and Z3 extinguishing
Manual-only mode local ON/OF
