Appendix A: Configuration presets
68 1X-X3 Installation Manual
Input and output configuration
Table 28: Inputs and outputs
IN1 Start MCP Supervised
IN2 Hold MCP Supervised
IN3 Abort MCP Supervised
IN4 Manual-only mode activation Unsupervised
IN5 Low pressure indication Supervised
IN6 Extinguishing agent flow Supervised
IN7 Safety door fault monitor Supervised
IN8 Remote reset Unsupervised
OUT1 Hold MCP Unsupervised
OUT2 Abort MCP Unsupervised
OUT3 Manual-only mode Unsupervised
OUT4 Extinguishing released Unsupervised
OUT5 Fire sounders Supervised
OUT6 Extinguishing sounders Supervised
OUT7
Extinguishing released optical
warning panels or signs
Supervised
OUT8 Actuator Supervised
Default delays
Table 29: Default delay configuration
Fire sounders delay 0
Fire routing delay [1] 0
Zone delay 0n
Released delay 10 seconds
[1] Requires installation of optional 2010-1-SB expansion board (not supplied).
Basic configuration modes
Basic standard mode
Fire sounders cannot be manually activated in this operating mode (fire sounders
are only activated if there is a fire alarm).
