Chapter 3: Configuration and commissioning
40 1X-X3 Installation Manual
The control panel provides three fire detection zones that can be assigned for
automatic detection of an extinguishing event. Fire detection zones that are not
linked to the extinguishing area are assigned standard fire detection functionality.
The configuration options available are shown below.
Option 1Z1. An alarm in Z1 initiates the extinguishing event. The control
panel provides standard fire detection for Z2 and Z3, both as mixed zones.
Option 2 Z1 and Z2. This is the default configuration). Both Z1 and Z2 must
be in alarm to initiate an extinguishing event. Z3 provides standard fire detection
as a mixed zone.
Option 3 Z1, Z2, and Z3. All three zones cover the extinguishing area. An
alarm in any two of the zones initiates an extinguishing event. None of the zones
provides standard fire detection functionality.
For more information, see “Connecting zones with initiating deviceson page 7.
To configure the extinguishing zones:
1. Set the display as shown below, and then press Enter.
The Zone yellow LEDs flash quickly to indicate that the configuration menu is
active.
2. Select a value using the value selection buttons (2 and 4).
3. Press Enter.
4. Save your changes.
The available settings for this feature are shown below.
Display Description
Z1 is configured as an extinguishing zone.
Z2 and Z3 are configured as fire detection zones.
Z1 and Z2 are configured as extinguishing zones.
Z3 is configured as a fire detection zone.
Z1, Z2, and Z3 are configured as extinguishing zones.
No fire detection zones are provided.
Manual-only mode local
When the control panel is in manual-only mode, the extinguishing process can
only be initiated manually, using the MCP Start device. Automatic extinguishing
events reported from the fire detection zones are disabled for extinguishing
activation.
