Aritech 1X-X3 Installation Manual

Appendix A: Configuration presets
1X-X3 Installation Manual 69
The configured actuator delay is applied when the MCP Start is activated.
Table 30: Presets and zone characteristics
Preset Zone description Zone detection
01 Passive Z1 and Z2 automatic, for extinguishing event
Z3 mixed, for fire detection
02 Passive, CleanMe enabled Z1 and Z2 automatic, for extinguishing event
Z3 mixed, for fire detection
Basic evacuation mode
Fire sounders can be manually activated at the operator user level in this
operating mode (a fire alarm is not required).
The actuator is activated immediately when the MCP Start is activated.
Table 31: Presets and zone characteristics
Preset Zone description Zone detection
04 Passive Z1 and Z2 automatic, for extinguishing event
Z3 mixed, for fire detection
05 Passive, CleanMe enabled Z1 and Z2 automatic, for extinguishing event
Z3 mixed, for fire detection
Expansion board functions
Table 32: Expansion board functions
Preset ON status Output Delay
01 Z1 alarm 1 Yes
Z2 alarm 2 Yes
Z3 alarm 3 Yes
05 Z1 alarm 1 Yes
2 Yes
Z2 alarm 3 Yes
4 Yes
06 Z3 alarm 1 Yes
2 Yes
22 Z1 and Z2 alarm 1 Yes
2 Yes
Z2 and Z3 alarm 3 Yes
4 Yes
