Aritech 1X-X3 Installation Manual

Chapter 3: Configuration and commissioning
1X-X3 Installation Manual 41
The panel can be switched to manual-only mode using two methods: the panel
Manual Mode button (local), or a manual-only mode activation device (remote).
Use this option to configure which method is used to switch to manual-only
mode. The default configuration is to use the panel button (i.e. to use local
control), so manual-only mode local is ON.
For more information see “Connecting an external device for manual-only mode
control” on page 12.
To configure the manual-only mode control:
1. Set the display as shown below, and then press Enter.
The yellow Manual Mode LED flashes fast to indicate that the configuration
menu is active.
2. Select a value using the value selection buttons (2 and 4).
3. Press Enter.
4. Save your changes.
The available settings for this feature are shown below.
Display Description
Manual-only mode is set locally. Manual-only mode is
activated by the Manual Mode button on the panel.
Manual-only mode is set remotely. Manual-only mode is
activated by the manual-only mode activation device.
Actuator delay for start MCP
Use this menu to configure the control panel behaviour after a manual
extinguishing event (from the MCP Start point): activate the actuator immediately
or apply the actuator delay configured for automatic extinguishing events.
The default settings are:
• Basic standard mode = ON
• Basic evacuation mode = OF
To configure the actuator delay for start MCP:
1. Set the display as shown below, and then press Enter.
The red Start MCP LED flashes fast to indicate that the configuration menu is
active.
