4.3.21 Cache operations
The purpose of c7 is to manage the associated caches. The maintenance operations are formed
into two management groups:
• Set and Way:
— clean
— invalidate
— clean and invalidate.
• Address, usually labelled MVA for Modified Virtual Address, but on this processor all
addresses are identical:
— clean
— invalidate
— clean and invalidate.
In addition, the maintenance operations use these definitions:
Point of Coherency (PoC)
A point where all instruction and data walks are transparent to any processor in
the system.
Point of Unification (PoU)
A point where instruction and data become unified and self-modifying code can
function.
Figure 4-37 on page 4-59 shows the arrangement of the functions in this group that operate with
the
MCR
and
MRC
instructions.
The following operations, as Figure 4-37 on page 4-59 shows, are implemented as No
Operation,
NOP
, on the processor:
• Wait For Interrupt, CRm= c0, Opcode_2 = 4
• Invalidate Entire Branch Predictor Array, CRm= c5, Opcode_2 = 6
• Invalidate Branch Predictor Array Line using MVA, CRm= c5, Opcode_2 = 7.
The Wait For Interrupt (
WFI
) instruction provides the Wait For Interrupt function. For more
information see the ARM Architecture Reference Manual.
