Level One Memory System
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. 8-28
ID073015 Non-Confidential
• Write a line to the eviction buffer in one cycle, a 256-bit read access.
• Fill a line in one cycle from the linefill buffer, a 256-bit write access.
Figure 8-3 shows a cache look-up being performed on all banks with one RAM access.
Figure 8-3 Nonsequential read operation performed with one RAM access.
Figure 8-4 shows the appropriate bank RAM being selected for a sequential read operation.
Figure 8-4 Sequential read operation performed with one RAM access
The data RAM organization is optimized for 64-bit read operations, because with the same
address, two words on the same way can be selected.
Data RAM sizes depend on the build option selected, and are described in:
• Data RAM sizes without parity or ECC implemented on page 8-29
• Data RAM sizes with parity implemented on page 8-29
• Data RAM sizes with ECC implemented on page 8-30.
