ARM Cortex-R4 - Page 237

Level Two Interface
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. 9-14
ID073015 Non-Confidential
Table 9-15 shows possible values of ARADDRM, ARBURSTM, ARSIZEM, and ARLENM
for a Non-cacheable
LDR or an LDM that transfers one register, an LDM 1.
Table 9-16 show possible values of ARADDRM, ARBURSTM, ARSIZEM, and ARLENM
for a Non-cacheable
LDM that transfers five registers (an LDM 5).
0x4 (byte 4) 0x04 Incr 16-bit 1 data transfer
0x5 (byte 5) 0x04 Incr 32-bit 1 data transfer
0x6 (byte 6) 0x06 Incr 16-bit 1 data transfer
0x7 (byte 7) 0x07 Incr 32-bit 2 data transfers
Table 9-15 LDR or LDM1 from Non-cacheable Normal memory
Address[2:0] ARADDRM ARBURSTM ARSIZEM ARLENM
0x0 (byte 0) (word 0) 0x00 Incr 32-bit 1 data transfer
0x1 (byte 1) 0x01 Incr 64-bit 1 data transfer
0x2 (byte 2) 0x00 Incr 64-bit 1 data transfer
0x3 (byte 3) 0x00 Incr 64-bit 2 data transfers
0x4 (byte 4) (word 1) 0x04 Incr 32-bit 1 data transfer
0x5 (byte 5) 0x05 Incr 32-bit 2 data transfers
0x6 (byte 6) 0x06 Incr 16-bit 1 data transfer
0x08 Incr 16-bit 1 data transfer
0x7 (byte 7) 0x04 Incr 32-bit 2 data transfers
Table 9-16 LDM5, Non-cacheable Normal memory or cache disabled
Address[4:0] ARADDRM ARBURSTM ARSIZEM ARLENM
0x00 (word 0) 0x00 Incr 64-bit 3 data transfers
0x04 (word 1) 0x04 Incr 64-bit 3 data transfers
0x08 (word 2) 0x08 Incr 64-bit 3 data transfers
0x0C (word 3) 0x0C Incr 64-bit 3 data transfers
0x10 (word 4) 0x10 Incr 64-bit 2 data transfers
0x00 Incr 32-bit 1 data transfer
0x14 (word 5) 0x14 Incr 64-bit 2 data transfers
0x00 Incr 64-bit 1 data transfer
Table 9-14 LDRH from Non-cacheable Normal memory (continued)
Address[2:0] ARADDRM ARBURSTM ARSIZEM ARLENM
