Level Two Interface
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. 9-25
ID073015 Non-Confidential
9.6.1 TCM RAM access
Table 9-27 shows the decode of the ARUSERS[3:0] signal, and the state of the address signals
for accessing the TCM RAMs. The table also shows the SLBTCMSB configuration input signal
that determines the address bit that is used, either:
• ARADDRS[3]
• ARADDRS[MSB], see Table 9-28.
In Table 9-27 ARADDRS[MSB] means the most significant address bit for the TCM RAM,
and Table 9-28 shows the MSB bit for the different TCM RAM sizes.
ARADDRS[22:3] indicates the address of the doubleword within the TCM that you want to
access. If you are accessing a TCM that is smaller than the maximum 8MB, then it is possible
to address a doubleword that is outside of the physical size of the TCM.
An access to the TCM RAMs is given a SLVERR error response if:
• It is outside the physical size of the targeted TCM RAM, that is, bits of
ARADDRS[22:MSB+1] are non-zero.
Table 9-27 TCM chip-select decode
BTCM ports ARUSERS[3:0] ARADDRS[3] ARADDRS[MSB] SLBTCMSB RAM selected
Don’t care 0001 - - - ATCM
1 0010 - - - B0TCM
2 0010 0 - 0 B0TCM
2 0010 1 - 0 B1TCM
2 0010 - 0 1 B0TCM
2 0010 - 1 1 B1TCM
Table 9-28 MSB bit for the different TCM RAM sizes
TCM size ARADDRS[MSB]
4KB [11]
8KB [12]
16KB [13]
32KB [14]
64KB [15]
128KB [16]
256KB [17]
512KB [18]
1MB [19]
2MB [20]
4MB [21]
8MB [22]
