AC Characteristics
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. B-4
ID073015 Non-Confidential
Table B-3 shows the timing parameters for the interrupt input ports.
Table B-4 shows the input timing parameters for the AXI master port.
Clock uncertainty 20% PARLVRAM
Clock uncertainty 20% ENTCM1IF
Clock uncertainty 20% SLBTCMSB
Clock uncertainty 20% RMWENRAM[1:0]
Table B-3 Interrupt input ports timing parameters
Input delay
minimum
Input delay
maximum
Signal name
Clock uncertainty 60% nFIQ
Clock uncertainty 60% nIRQ
Clock uncertainty 10% INTSYNCEN
Clock uncertainty 60% IRQADDRV
Clock uncertainty 60% IRQADDRVSYNCEN
Clock uncertainty 60% IRQADDR[31:2]
Table B-4 AXI master input port timing parameters
Input delay
minimum
Input
delay
maximum
Signal name
Clock uncertainty 50% ACLKENM
Clock uncertainty 60% AWREADYM
Clock uncertainty 60% WREADYM
Clock uncertainty 60% BIDM[3:0]
Clock uncertainty 60% BRESPM[1:0]
Clock uncertainty 60% BVALIDM
Clock uncertainty 60% ARREADYM
Clock uncertainty 60% RIDM[3:0]
Clock uncertainty 60% RDATAM[63:0]
Clock uncertainty 60% RRESPM[1:0]
Clock uncertainty 60% RLASTM
Table B-2 Configuration input port timing parameters (continued)
Input delay
minimum
Input delay
maximum
Signal name
