C.19 Floating-point register transfer instructions
This section describes the cycle timing behavior for the various VFP instructions that transfer
data between the VFP register file and the integer register file, including the system registers.
All source operands are Normal Regs, and the result latency for non-system register transfers is
always 1 cycle.
Instructions that write data from the integer register file to the VFP system registers (
FMXR ) are
blocking, that is, no subsequent instruction can start execution before the
FMXR has completed
execution. Consequently, the
FMXR instructions take six cycles to execute.
All transfers to and from the VFP system registers are also serializing. This means that if there
are any outstanding out-of-order-completion VFP instructions, the system register transfer
instruction stalls in the iss-stage until these instructions are complete.
VFP instructions that complete out-of-order are
VMLA.F32 , VMLS.F32 , VNMLS.F32 , VNMLA.F32 ,
VDIV.F32 , VSQRT.F32 , VCVT.F64.F32 , and double-precision arithmetic and conversion instructions.
Table C-24 shows the floating-point register transfer instructions cycle timing behavior.
Table C-24 Floating-point register transfer instructions cycle timing behavior
Example instruction Cycles Result latency Comments
VMOV <Sn>, <Rt> 11 -
VMOV <Rt>, <Sn> 12 -
VMOV <Dn[x]>, <Rt> 11 -
VMOV.<dt> <Rt>, <Dn[x]> 12 -
VMOV <Sm>, <Sm1>, <Rt>, <Rt2> 11 -
VMOV <Rt>, <Rt2>, <Sm>, <Sm1> 12 -
VMOV <Dm>, <Rt>, <Rt2> 11 -
VMOV <Rt>, <Rt2>, <Dm> 12 -
VMSR <spec_reg>, <Rt> 6 - Blocking and serializing
VMRS <Rt>, <spec_reg> 12 Serializing
VMRS APSR_nzcv, FPSCR 1- Serializing
