3.6.11 The M bits
M[4:0] are the mode bits. These bits determine the processor operating mode as Table 3-3
shows.
• In Privileged mode an illegal value programmed into M[4:0] causes the processor to enter
System mode.
• In User mode M[4:0] can be read. Writes to M[4:0] are ignored.
3.6.12 Modification of PSR bits by MSR instructions
In the ARMv7-R architecture each CPSR bit falls into one of these categories:
• Bits that are freely modifiable from any mode, either directly by
MSR
instructions or by
other instructions whose side-effects include writing the specific bit or writing the entire
CPSR.
Bits in Figure 3-4 on page 3-9 that are in this category are N, Z, C, V, Q, GE[3:0], and E.
• Bits that an
MSR
instruction must never modify, and so must only be written as a side-effect
of another instruction. If an
MSR
instruction tries to modify these bits, the results are
architecturally Unpredictable. In the processor these bits are not affected.
The bits in Figure 3-4 on page 3-9 that are in this category are the execution state bits
[26:24], [15:10], and [5].
• Bits that can only be modified from Privileged modes, and that instructions completely
protect from modification while the processor is in User mode. Entering a processor
exception is the only way to modify these bits while the processor is in User mode, as
described in Exceptions on page 3-14.
Bits in Figure 3-4 on page 3-9 that are in this category are A, I, F, and M[4:0].
Table 3-3 PSR mode bit values
M[4:0] Mode
b10000 User
b10001 FIQ
b10010 IRQ
b10011 Supervisor
b10111 Abort
b11011 Undefined
b11111 System
