ASIX Forte - 2.7 Technical Specifications; 2.7.1 Limit Values; 2.7.2 Operating Specifications

Page 29
2.7
Technical Specifications
2.7.1 Limit Values
Operating temperature
min. 0°C
max. +55°C
Storage temperature
min. -40°C
max. +85°C
Voltage at any pin
1
min. -0.5V
max. 6.5V
Maximum current on I/O pin
50mA
ESD protection (HBM model)
±4kV kontakt
±8kV vzduch
Table9: Limit values
1
Pin P configured as an output has a voltage within a
range of +6.5V to +17V.
2.7.2 Operating
Specifications
Important Warning
Failure to respect these parameters may
damage the programmer or the connected
computer.
VDD feeding voltage
supplied by programmer
1.8V to 5.5V
VDD feeding voltage
supplied by application
1.8V to 5.5V
VDD external feeding voltage
for communication at limited
speed
1
1.2V to 5.5V
Maximum current drawn
from VDD
100mA
Maximum current drawn
from VPP
100mA at 7V
10mA at 17V
Maximum current drawn
from I/O pin
4mA @ VDD = 1.8V
16mA @ VDD = 4.5V
Maximum current drawn
from all I/O pins
simultaneously
100mA
Allowed input voltage on pins
0 to 5.5V
P pin output voltage
Adjustable from 6.5V to 17V or
logic levels
VIL input voltage
max. VDD x 0.3V
VIH input voltage
min. VDD x 0.7V
VOL output voltage
max. 0.55V @ VDD=4.5V
@I=4mA
typ. 0.1V
VOH output voltage
min. 3.8V @ VDD=4.5V @I=4mA
typ. VDD - 0.1V
Resistance to short circuiting
permanent
