5.7.1 List of Commands
Unless specified otherwise, the command returns to its
return value:
0 error, failed
1 everything worked OK
Commands with a wParam of 1, 2, 3, 4, 5, 6, 7 and 24 are
thread blocking.
wParam
lParam
Description
0
0
does not perform anything, returns 1
1
SetForegroundWindow()
2
Maximize, SetForegroundWindow()
1
any
programs everything, same return code as
from the command line
2
any
programming excl. data memory, same
return code as from the command line
3
see
below
programming incl. erasing, same return code
as from the command line
bit 0 = 1
code/main memory
bit 1 = 1
data memory (EEPROM)
bit 2 = 1
configuration memory
bit 3 = 1
boot memory (MSP430, CC430)
4
see
below
reading
bit 0 = 1
code/main memory
bit 1 = 1
data memory (EEPROM)
bit 2 = 1
configuration memory
bit 3 = 1
boot memory (MSP430, CC430)
5
see
below
differential programming
bit 0 = 1
code/main memory
bit 1 = 1
data memory (EEPROM)
bit 2 = 1
configuration memory
bit 3 = 1
boot memory (MSP430, CC430)
6
see
below
verification
bit 0 = 1
code/main memory
bit 1 = 1
data memory (EEPROM)
bit 2 = 1
configuration memory
bit 3 = 1
boot memory (MSP430, CC430)
7
see
below
erasing, same return code as from the
command line
bit 0 = 1
code/main memory
bit 1 = 1
data memory (EEPROM)
bit 3 = 1
boot memory (MSP430, CC430)
8
see
below
BlankCheck of memory, same return code as
from the command line
bit 0 = 1
code/main memory
bit 1 = 1
data memory (EEPROM)
bit 2 = 1
configuration memory
bit 3 = 1
boot memory (MSP430, CC430)
15
any
presses the GO button, returns 1
16
see
below
asks if the programmer supports the function
0
MCLRControl_Run
1
MCLRControl_Stop
2
MCLRControl_Reset
8
current voltage at pin VDD
17
see
below
performs the programmer function
0
MCLRControl_Run
1
MCLRControl_Stop
2
MCLRControl_Reset
8
current voltage at pin VDD
return value PRESTO:
0 – unknown level
1 – 0 V
2 – approx. 2 V
3 – approx. 5V
