Max Current – Steady State 2.4 Amps @ 28 VDC
4.8 Amps @ 14 VDC
Max Current – Peak 7.0 Amps @ Maximum
I/O SPECIFICATIONS
ARINC 429 Inputs 1
ARINC 429 Outputs
RS-232 Inputs
RS-232 Outputs
Pitot / Static Quick Connect
CERTIFICATION SPECIFICATIONS
FAA Technical Standard Order
EASA (European Aviation Safety Agency)
ETSO (European Technical Standard
Order)
TSO-C2d / ETSO-C2D.......................................................................Airspeed Instruments
TSO-C3d / ETSO-C3D................................................................Turn and Slip Instrument
TSO-C4c / ETSO-C4C...........................................................Bank and Pitch Instruments
TSO-C6d / ETSO-C6D..................................................Direction Instrument Magnetic
(Gyroscopically Stabilized)
TSO-C8d / ETSO-C8D.......................Vertical Velocity Instrument (Rate of Climb)
TSO-C10b / ETSO-C10B......................Altitude Pressure Activated Sensitive Type
TSO-C106 / ETSO-C106.........................................................................Air Data Computer
TSO-C113 / ETSO-C113....................Airborne Multipurpose Electronic Displays
Software RTCA DO-178B Level C
Environmental RTCA DO-160E
Categories See Environmental Qualication Sheet found in the Installation Manual.
Table 7-1
Evolution Backup Display Unit (EBD) Specications
