7.3. Specications
7.3.1. Evolution Display Unit (EBD)
GENERAL SPECIFICATIONS
Width 7.00 in. (Measured at Bezel)
Height 3.50 in. (Measured at Bezel)
Can Depth 4.15 in. (Rear of Bezel to Rear of Can)
Overall Depth 6.35 in. (Knob to Rear Pressure Fitting)
Weight 2.9 lbs. (with Mounting Bracket)
Display Type 6.0 in. Diagonal TFT Active Matrix LCD (400x760)
Display Colors 32,768
Face Anti-Reective Coated Glass
Backlight High Intensity White LED
Rotary Knobs Optical Encoder with Momentary Press
Dimming Manual & Automatic (Front Bezel Mounted Sensor)
OPERATIONAL SPECIFICATIONS
Operating Temp -20°C to +70°C
Storage Temp -55°C to +85°C
Max Un-Pressurized Operating Altitude 35,000 ft.
Max Pressurized Operating Altitude 55,000 ft.
Cooling Integral Fan
Max Humidity 95% at 50°C
Input Voltage +8 to +32 Volts DC
