CHAPTER 2 CONTROLS AND DISPLAY
Page 2-16
091-00027-001 REV A Evolution Backup Display Pilot’s Guide
Page 2-17
091-00027-001 REV A
2.3. Display
The EBD Basic is a digital backup for the Attitude Indicator and DG. The left half presents
an Attitude Display and the right half contains a Navigation Display (Figure2-15 and
Table 2-8). Between the two halves is the Data Bar. The Data Bar contains a dedicated
display of real-time winds, Outside Air Temperature (OAT), True Airspeed (TAS), and GPS
Ground Speed (GS).
Attitude Display
Data Bar
Navigation Display
Table 2-8
EBD Display Areas
Figure 2-15
EBD Display Areas
Figure 2-15a
EBD Display areas with callouts
